Jumbo Size Injection Molding Machine

  • Rubber & Silicone Injection Molding Machine
Rubber & Silicone Injection Molding Machine
Prev Next
TIP-15000-2RT-L-1200-PCD
Clamping Force:1200 tons
Injection Volume:15000 c.c.
Highlights:

  • Horizontal injection unit to decrease the press height and suitable for premise limit.
  • Suitable for bladder production to increase the bladder life and save materials.
  • With mold safety design on the hydraulic system to detect the abnormal pressure before mold close.
Application Examples：
  • Tire bladders



Technical Specifications：
Machine Type   TIP-L Vertical
Injection Unit
Injection Volume c.c. 100 500 1000 2000 3000 3000
Injection Pressure kg / cm2 1500~2000
Injection Flow c.c. / sec 35 65 76 134 175 175
Clamping Unit
Clamping Force tons 100 150 200 250 350 500
Heating Platen
(L.R. X F.B.)		 mm 400 X 400 450 X 500 450 X 500 570 X 610 700 X 700 800 X 800
Daylight mm 250 400~600 450~650 500~650 500~700 500~700
Stroke mm 250 350 350 / 400 400 400 400
Mold Thickness mm 150 50~400 100~600 100~600 100~650 100~650
